System specifications
RMS/AES power handling    4 x 600 W
Frequency    Response (± 3 dB)    50 Hz - 20 kHz
Signal / Noise    < 95 dB
Crosstalk (@ 1 kHz)    > 70 dB
Min. load impedance    8 Ω
Technology    Class-D
Power    Supply    Switching mode
AC Input: 100-120V/220-240V~ 50/60Hz
Note: Standard voltage and frequency of electricity varies from country to country. Please contact your local distributor to ensure suitable product variant voltage and frequency compatibility.
Inputs    Sensitivity    -30 dB ~ +5 dB
Impedance    10 kΩ balanced
Common mode rejection ratio    70 dB
Damping factor    > 200
Protection    Amplifier    DC Short circuit
                                      Over heating
                                      Over load
                                      Signal limiting
Access    User & Administrator level (Through password and USB-key protection)
Cooling    Temperature controlled fan
Operating temperature    0° ~ 40° @ 95% Humidity
Inputs    Connector    XLR & 3-pin Euro Terminal Block (3.81 mm)
Outputs    Connector    4-pin Euro Terminal Block (Pitch - 5.08 mm)
THD+N (@ 1 kHz)    < 0.05% (1/2 Rated Power)
Product Features
Dimensions    482 x 88 x 420 mm (W x H x D)
Weight    8.6 kg
Mounting    19”
