System specifications
Inputs    Bluetooth receiver
Front 3.5mm Jack (mixed with Ch 2)
Priority mute contact
Microphone    Signal / Noise    > 80 dB
Line    Signal / Noise    > 100 dB
Balanced Microphone    THD+N (@ 1 kHz)    < 0.05 dB
Line    THD+N (@ 1 kHz)    < 0.01 dB
Frequency    Response (± 3 dB)    20 Hz - 20 kHz
Power    Supply    100 ~ 240 V AC / 50 ~ 60 Hz
Inputs    Balanced Microphone    Type    8 x Balanced Microphone
Unbalanced Stereo    Type    2 x Stereo Unbalanced Line
Outputs    Balanced Stereo    Type    2 x Balanced Stereo outputs
Inputs    Microphone    Phantom Power    48 V DC
Product Features
Dimensions    482 x 88 x 335 mm (W x H x D)
Unit height    2 HE
